Majan Switchgear Co. LLC.




Aluminium Enclosures



  • Single wall and double wall enclosures designed to IP 55
  • Special EPDM steel ribbed gaskets and polyamide black hinges
    providing 180 degree openability
  • High corrosion resistance suitable for outdoor applications
  • Electro-galvanised steel mounting plate
  • Twin bit lock / swing handle with keys (optional)
  • Metal reinforcement stiffener on the inside of the door also serves effective gasketting for ingress protection
  • High quality and precision welding
  • Air gap of 25mm between walls for double wall enclosures to ensure adequate airflow. This prevents moisture in the inner cabinet in humid conditions.
  • 100mm plinth provided (optional)
Colour :
  • Powder coated RAL 7032 matt texture finish.
  • Mounting plate: Powder coated RAL 2000, semi glossy finish.
